Standard ISO Pallet Wide Container
The 40’ Pallet Wide Container (ISO 4CG1) is a general purpose shipping container specifically designed to maximize pallet loading efficiency. Manufactured in accordance with ISO and CSC requirements, it provides increased internal width compared with a standard 40-foot container, allowing two Euro pallets to be loaded side by side with minimal unused space. The ISO code 4CG1 identifies a 40-foot Pallet Wide General Purpose Container.
The wider internal dimensions make the container particularly suitable for palletised cargo, retail distribution, manufacturing logistics and warehouse operations while remaining fully compatible with international intermodal transport by sea, rail and road.
Technical Specifications
| pecification | Value |
|---|---|
| ISO Code | 4CG1 |
| External Length | 12,192 mm |
| External Width | 2,462 mm |
| External Height | 2,591 mm |
| Internal Length | 12,032 mm |
| Internal Width | 2,414 mm |
| Internal Height | 2,392 mm |
| Door Opening Width | 2,359 mm |
| Door Opening Height | 2,290 mm |
| Maximum Gross Weight | 30,480 kg |
| Tare Weight | 3,800 kg |
| Maximum Payload | 26,680 kg |
| Cubic Capacity | 70.2 m³ |
External Dimensions
The external dimensions are optimized for European pallet transport while remaining compatible with international logistics equipment.
- Length: 12,192 mm
- Width: 2,462 mm
- Height: 2,591 mm
The wider construction provides greater loading efficiency without compromising handling operations.
Internal Dimensions
The wider cargo compartment has been designed to maximize usable pallet space.
- Length: 12,032 mm
- Width: 2,414 mm
- Height: 2,392 mm
With a capacity of 70.2 m³, the container accommodates more palletised cargo than a standard 40-foot container.
Door Opening
Full-width cargo doors provide excellent access for forklifts and warehouse equipment.
Door opening dimensions:
- Width: 2,359 mm
- Height: 2,290 mm
The increased door width simplifies loading of Euro pallets placed side by side.
Payload & Weight Ratings
The reinforced construction provides high payload capacity while maintaining excellent structural strength.
- Maximum Gross Weight: 30,480 kg
- Tare Weight: 3,800 kg
- Maximum Payload: 26,680 kg
Actual payload depends on the manufacturer and container configuration.
Loading Capacity
Typical loading configuration includes:
- 30 Euro pallets (1200 × 800 mm)
- 24 Industrial pallets (1200 × 1000 mm)
- 70.2 cubic metres of cargo volume
Actual loading capacity depends on cargo dimensions, packaging and weight distribution.
Pallet Wide Design
The 4CG1 Pallet Wide Container features:
- Increased internal width
- Wider door opening
- Standard rear cargo doors
- Reinforced steel frame
- Marine plywood floor
- Multiple cargo lashing points
- ISO corner castings
The wider interior allows two Euro pallets to fit side by side, reducing unused space and improving transport efficiency.
Construction
The structure is manufactured from high-strength Corten steel, providing excellent durability under demanding operating conditions.
Standard construction features include:
- Reinforced steel frame
- Marine plywood floor
- Weather-resistant door seals
- CSC certification
- ISO corner castings
- Forklift handling compatibility
Applications
The 40’ Pallet Wide Container is commonly used for:
- Euro pallet transport
- Retail logistics
- FMCG distribution
- Manufacturing
- Warehouse storage
- Consumer goods
- Food products
- Packaging materials
- Industrial products
- General freight
Standards & Certification
This container type complies with internationally recognised transport standards, including:
- ISO 668
- ISO 6346
- CSC Convention
- International intermodal transport requirements
These standards ensure worldwide compatibility with ports, depots, shipping lines and logistics operators.
Frequently Asked Questions
What does ISO code 4CG1 mean?
4CG1 identifies a 40-foot Pallet Wide General Purpose Container designed with increased internal width for more efficient pallet transport.
What is the advantage of a Pallet Wide Container?
The wider interior allows two Euro pallets to be loaded side by side, maximizing cargo space and reducing empty gaps.
How many pallets fit inside?
The container accommodates approximately 30 Euro pallets or 24 Industrial pallets, depending on the loading configuration.
What is the maximum payload?
The maximum payload is approximately 26,680 kg.
Is the container suitable for international shipping?
Yes. It is designed for international intermodal transport by sea, rail and road while offering improved pallet loading efficiency.
