Standard ISO Open Top Container
The 40’ Open Top Container (ISO 42U1) is designed for cargo that cannot be loaded through standard container doors due to its height, weight or loading method. Built in accordance with ISO and CSC requirements, it features a removable tarpaulin roof and detachable roof bows, allowing cargo to be loaded from above using cranes or other lifting equipment. The ISO code 42U1 identifies a standard 40-foot Open Top Container.
Its versatile design makes it suitable for transporting oversized, heavy and over-height cargo while remaining fully compatible with international intermodal transport by sea, rail and road.
Technical Specifications
| Specification | Value |
|---|---|
| ISO Code | 42U1 |
| External Length | 12,192 mm |
| External Width | 2,438 mm |
| External Height | 2,591 mm |
| Internal Length | 12,029 mm |
| Internal Width | 2,342 mm |
| Internal Height | 2,326 mm |
| Door Opening Width | 2,336 mm |
| Door Opening Height | 2,280 mm |
| Maximum Gross Weight | 30,480 kg |
| Tare Weight | 3,810 kg |
| Maximum Payload | 26,670 kg |
| Cubic Capacity | 65.5 m³ |
External Dimensions
The external dimensions comply with ISO standards, allowing unrestricted use across international container transport systems.
- Length: 12,192 mm
- Width: 2,438 mm
- Height: 2,591 mm
The standardized footprint enables efficient handling by container cranes, reach stackers, trucks and railway wagons.
Internal Dimensions
The cargo compartment has been designed to maximize usable loading volume while allowing top loading when required.
- Length: 12,029 mm
- Width: 2,342 mm
- Height: 2,326 mm
With a capacity of 65.5 m³, the container is suitable for oversized and over-height cargo.
Door Opening
Full-width cargo doors allow loading by forklift or warehouse equipment whenever top loading is not required.
Door opening dimensions:
- Width: 2,336 mm
- Height: 2,280 mm
For oversized cargo, the removable roof provides unrestricted access from above.
Payload & Weight Ratings
The reinforced construction provides excellent structural strength while maintaining a high payload capacity.
- Maximum Gross Weight: 30,480 kg
- Tare Weight: 3,810 kg
- Maximum Payload: 26,670 kg
Actual payload depends on the manufacturer and container configuration.
Loading Capacity
Typical loading configuration includes:
- Machinery
- Industrial equipment
- Steel structures
- Timber
- Pipes
- Marble and stone products
- Heavy project cargo
- Over-height cargo
Actual loading capacity depends on cargo dimensions, packaging and lifting method.
Open Top Design
The removable tarpaulin roof allows loading and unloading from above using cranes, making the container suitable for cargo exceeding the standard door height.
Typical features include:
- Removable tarpaulin roof
- Removable roof bows
- Full-width double cargo doors
- Crane loading capability
- Lashing points for cargo securing
Construction
The structure is manufactured from high-strength Corten steel, providing excellent durability under demanding operating conditions.
Standard construction features include:
- Removable roof system
- Steel side walls
- Marine plywood floor
- Weather-resistant tarpaulin
- CSC certification
- ISO corner castings
- Forklift handling compatibility
Applications
The 40’ Open Top Container is commonly used for:
- Over-height cargo
- Industrial machinery
- Construction equipment
- Steel products
- Timber
- Pipes
- Stone products
- Project cargo
- Manufacturing equipment
- Export cargo
Standards & Certification
This container type complies with internationally recognised transport standards, including:
- ISO 668
- ISO 6346
- CSC Convention
- International intermodal transport requirements
These standards ensure worldwide compatibility with ports, depots, shipping lines and logistics operators.
Frequently Asked Questions
What does ISO code 42U1 mean?
42U1 identifies a standard 40-foot Open Top Container designed for cargo requiring loading from above.
What is the advantage of an Open Top Container?
The removable roof allows cargo to be loaded and unloaded by crane, making it suitable for over-height or heavy cargo.
What is the internal volume?
The internal cargo volume is 65.5 cubic metres.
What is the maximum payload?
The maximum payload is 26,670 kg.
Is the container suitable for international shipping?
Yes. It is designed specifically for international intermodal transport by sea, rail and road.
